Tubing Pumps
Sandur Fluid Controls Pvt. Ltd. offers high-quality Tubing Pumps engineered for precise, contamination-free, and reliable fluid transfer applications. Designed using advanced peristaltic pumping technology, these pumps provide accurate dosing and smooth fluid handling for a wide range of industrial, laboratory, medical, and chemical processing applications.
Tubing Pumps are ideal for handling corrosive, viscous, abrasive, sterile, and shear-sensitive liquids without direct contact between the fluid and pump components. These pumps are widely used in pharmaceuticals, laboratories, water treatment systems, food & beverage industries, biotechnology, chemical processing, and OEM equipment.
Tubing Pumps, also known as Peristaltic Pumps, operate using a rotating roller mechanism that compresses flexible tubing to move fluids accurately through the pump without contamination.
The fluid only comes into contact with the tubing, making these pumps highly suitable for sterile, corrosive, and sensitive liquid handling applications.
Our Tubing Pumps are available in manual, analog, and digital control configurations with compact and industrial-grade designs suitable for continuous-duty operation and automation integration.
Product Features :
Technical Specifications :
| Parameter | Specification |
|---|---|
| Product Type | Tubing / Peristaltic Pump |
| Pump Technology | Roller Compression Peristaltic Mechanism |
| Flow Rate Range | 1 ml/min to 300 LPH |
| Maximum Pressure | Up to 8 Kg/cm² |
| Dosing Accuracy | ±1% |
| Flow Control | Manual / Analog / Digital |
| Power Supply | 12V DC / 24V DC / 230V AC |
| Motor Type | AC / DC / Stepper Motor |
| Tubing Material | Silicone / Santoprene / Viton / Tygon |
| Housing Material | PP / ABS / SS304 / SS316 |
| Protection Class | IP55 / IP65 |
| Mounting Type | Panel / Wall / Table / Skid Mounted |
| Flow Direction | Reversible |
| Operating Mode | Continuous Duty |
| Automation Compatibility | PLC / SCADA Compatible |
| Operating Temperature | Up to 60°C |
Available Pump Types :
Laboratory Tubing Pumps :
Features :
Applications :
Industrial Tubing Pumps :
Features :
Applications :
Digital Tubing Pumps :
Features :
Applications :
OEM Tubing Pumps :
Features :
Applications :
Standard Model Range :
| Model | Maximum Flow Rate | Maximum Pressure |
|---|---|---|
| TP-01 | 100 ml/min | 8 Kg/cm² |
| TP-05 | 500 ml/min | 6 Kg/cm² |
| TP-1 | 1 LPH | 5 Kg/cm² |
| TP-10 | 10 LPH | 4 Kg/cm² |
| TP-50 | 50 LPH | 3 Kg/cm² |
| TP-300 | 300 LPH | 2 Kg/cm² |
Applications :
Tubing Pumps are widely used across multiple industries.
Industries We Serve :
Optional Accessories :
Why Choose Our Tubing Pumps?
Frequently Asked Questions (FAQ)?
A Tubing Pump is a peristaltic pump that transfers fluid by compressing flexible tubing using rotating rollers.
They are used for precise, contamination-free fluid transfer and chemical dosing applications.
The pumps can handle corrosive chemicals, sterile liquids, viscous fluids, slurries, and sensitive liquids depending on tubing material.
No, the fluid only contacts the tubing, ensuring contamination-free operation.
Yes, tubing pumps can safely run dry for short durations.
Yes, manual, analog, and digital control options are available.
Silicone, Santoprene, Viton, and Tygon tubing options are available.
Yes, customized tubing pump systems can be developed for specific applications.
Yes, PLC and SCADA integration options are available.
Yes, genuine tubing kits and spare parts are available.
