Electrofetric
The Electrofetric Dosing System from Sandur Fluid Controls Pvt. Ltd. is an advanced electrochemical dosing and monitoring system designed for automatic chemical dosing, process parameter control, and industrial water treatment automation.
Engineered with intelligent digital controllers, precision dosing pumps, and electrochemical sensor technology, the Electrofetric system provides highly accurate monitoring and dosing of chemicals based on real-time process conditions.
The system is ideal for water treatment plants, cooling towers, swimming pools, RO plants, ETP/STP plants, chemical industries, food processing industries, and industrial automation applications where accurate process control and chemical dosing are critical.
The Electrofetric system is a smart dosing and monitoring solution that combines electrochemical sensors with automated dosing pumps to maintain critical process parameters such as pH, ORP, conductivity, chlorine levels, and TDS within desired ranges.
Designed for continuous-duty industrial operation, the system automatically measures process conditions and controls chemical dosing in real time, improving efficiency, reducing chemical wastage, and ensuring stable process performance.
The Electrofetric system can be customized with various pump configurations, control panels, communication interfaces, and sensor options based on application requirements.
Product Features :
Technical Specifications :
| Parameter | Specification |
|---|---|
| Product Type | Electrochemical Dosing & Monitoring System |
| Dosing Type | Automatic Sensor Based Dosing |
| Pump Type | Electromagnetic / Motor Driven |
| Number of Pumps | 1 to 8 Pumps (Customizable) |
| Flow Rate Range | As Per Application Requirement |
| Maximum Pressure | Up to 20 Kg/cm² |
| Dosing Accuracy | ±1% |
| Control Type | Microprocessor Based Controller |
| Display Type | Digital LCD / Touch Screen |
| Input Parameters | pH / ORP / Conductivity / Chlorine / TDS |
| Analog Input | 4–20 mA |
| Communication | PLC / SCADA Compatible |
| Power Supply | 230V / 415V AC |
| Wetted Materials | PP / PVDF / SS316 |
| Diaphragm Material | PTFE |
| Protection Class | IP65 |
| Mounting Type | Wall / Skid Mounted |
| Operating Mode | Automatic / Manual |
| Operating Temperature | Up to 50°C |
| System Configuration | Fully Customizable |
System Components :
The Electrofetric system may include :
Applications :
The Electrofetric system is suitable for a wide range of industrial and commercial applications.
Benefits of Electrofetric Systems :
Material of Construction :
| Component | Available Materials |
|---|---|
| Pump Head | PP / PVDF / SS316 |
| Diaphragm | PTFE |
| Tanks | HDPE / PP |
| Piping | PVC / UPVC / SS316 |
| Valve Ball | Ceramic / SS316 |
| Seals / O-Rings | Viton / PTFE |
Industries We Serve :
Optional Features & Accessories :
Why Choose Electrofetric Systems?
Frequently Asked Questions (FAQ)?
The Electrofetric system is an automated electrochemical monitoring and chemical dosing system.
The system can monitor pH, ORP, conductivity, chlorine, TDS, and other process parameters.
Yes, the system supports fully automated dosing based on sensor feedback.
Yes, PLC and SCADA integration options are available.
Water treatment, chemical processing, pharmaceuticals, food processing, cooling towers, swimming pools, and many industrial applications.
The system can support multiple dosing pumps depending on application requirements.
PP, PVDF, SS316, PTFE, HDPE, and other chemically resistant materials are available.
Yes, optional IoT, GSM, and SCADA remote monitoring features are available.
Yes, genuine spare parts, sensors, and technical support are available.
Yes, complete customization is available according to process requirements.
