Electromagnetic Dosing Pump B - Series
In the E & B range of pumps, the frequency can be varied between 4% & 100% and the stroke length between 10% & 100%. Thus, pump can operate in the range of 0.4% to 100% of the rated capacity. While the frequency can be adjusted in steps of 25%, 50% and 100%, the stroke length can be varied from 10% to 100% in CC3 series.
The pump also has an inbuilt facility for automatic control of dosing and can accept pulse signals or analogue signals of 0/4-20mA. The pump also has the additional feature for low-level indication in the dosing tank.
The pump is suitable for a power supply of single phase, 230V (AC).
- Die-casting aluminium powder coated pump body
- 0% to 100% Stroke frequency adjustment
- 10% to 100% stroke length adjustment
- Can accept pulse & 4-20mA signals
- 0.44 LPH to 54.60 LPH Capacity
- Maximum pressure of 25 Kgf/cm2
Product Feature
*Compact Size *Double Ball Check Valves *High Quality, Long lasting re-inforced PTFE Diaphragm *Maximum stroke length of only 1.25mm, hence maintenance free *Nolubrication needed *Discharge Rage Accuracy ± 1% *Handles any chemical *Can accept Potential Free Pulses and 4-20 mA signals *Discharge Countdown Ratio of 1:250 *Suitable for single phase power supply of 230V (C).
| Pump Model | Pressure (Bar) | Capacity (LPH) | Max.Strokes Per Minute | Nominal Power (Watt) | Instantaneous Power (Watt) | Tubing Size I/DXO/D (mm) | Suction Lift mWG | Shipping Weight(kg) |
|---|---|---|---|---|---|---|---|---|
| B 25001 | 25 | 1.44 | 120 | 55 | 230 | 6X8 | 6 | 6 |
| B 25005 | 25 | 4.22 | 110 | 120 | 548 | 6X8 | 6 | 11 |
| B 10006 | 10 | 5.76 | 120 | 55 | 230 | 6X8 | 5 | 6 |
| B 16010 | 16 | 9.9 | 110 | 120 | 548 | 6X8 | 6 | 11 |
| B 06012 | 6 | 11.93 | 120 | 55 | 230 | 6X8 | 3 | 6 |
| B 10013 | 10 | 12.95 | 110 | 120 | 548 | 9X12 | 5 | 11 |
| B 04017 | 4 | 16.71 | 120 | 55 | 230 | 9X12 | 2.5 | 6 |
| B 02035 | 1.25 | 34.92 | 120 | 55 | 230 | 9X12 | 1.5 | 6 |
| B 04026 | 4 | 26.4 | 110 | 120 | 548 | 9X12 | 1 | 12 |
| B 02055 | 1.5 | 54.6 | 110 | 120 | 548 | 19X27 | 1 | 12 |
- Pump heads are offered in PVC, PP, PTFE, Acrylic, MS & SS depending on the chemical to be handled.
- The shipping weights indicated above are for PVC, PP, PTFE & Acrylic pump heads and will vary for SS & MS.
- To select pump for specific application, following data is required.
- Chemical to be handled
- Capacity (litre/hr)
- Systems back pressure (bar)
- A wide range of accessories such as foot valve, dosing valve, check valve, pressure retaining valve, anti-siphon valve, pulsation dampener, level sensor, tank etc. are available on request to complete dosing system
